Parameter information
| Item | P2.5 | P3 | P4 | P5 | P6.67 | P8 | P10 |
| Pixel Pitch(mm) | 2.5 | 3 | 4 | 5 | 6.67 | 8 | 10 |
| Pixel Matrix Per Sq.m | 160,000dots | 111,111dots | 62,500dots | 40,000dots | 22,500dots | 15,625dots | 10000dots |
| Module Dimension(mm) | 320X160 | ||||||
| Cabinet Dimension(mm) | 960×960 | ||||||
| Cabinet Weight(kg) | 30 | ||||||
| Cabinet Material | Die Casting Aluminum | ||||||
| IP Rate | IP65 | ||||||
| Cabinet Resolution | 384×384 | 320×320 | 240×240 | 192×192 | 144×144 | 120×120 | 96×96 |
| Brightness(nits) | ≥5500 | ||||||
| Min Viewing Distance | 2.5m（8ft） | 3m(10ft) | 4m(13ft） | 5m(16.5ft) | 6.5m(21ft) | 8m(26ft) | 10m(33ft） |
| Color Temperature(K) | 6500-9000 | ||||||
| Gray Scale (bit) | 16 | ||||||
| Visual Angle(H/V) | 160°/ 160° | ||||||
| Max. Power Consumption | 800W | ||||||
| Ave. Power Consumption | 200-300W | ||||||
| Refreshing Ratio(Hz) | 3840 | ||||||
| Maintenance Method | Rear | ||||||
| Lifespan(hrs) | 100,000 | ||||||
| Input Voltage (AC) | 110V-240V,50/60HZ | ||||||
Comparison
Ningshine’s Outdoor Fixed Installation
Others
Warranty
Five-year warranty, we solemnly promise that during the warranty period, any problems caused by product quality will be replaced with new parts free of charge.
Warranty
2-3 years warranty, quality is not guaranteed.
brightness
High brightness, 5500nits, suitable for working under strong sunlight.
brightness
The brightness is low, and the display content is not clear under strong sunlight.
waterproof
IP65 waterproof, suitable for harsh outdoor climates.
waterproof
The waterproofing is not up to standard, causing water to enter and damage the LED screen.
cooling fan
Powerful cooling fan, good heat dissipation effect.
cooling fan
Poor quality cooling fan, poor cooling effect.
cabinet
Die-cast aluminum cabinet, thinner and lighter, with higher flatness.
cabinet
The iron cabinet is heavy and has poor flatness.
lamp beads
High quality lamp beads, lifespan more than 100,000 hours.
lamp beads
Poor quality lamp beads, damage quickly.
refresh
High refresh IC, 3840HZ refresh, eliminate ghosting and horizontal stripes.
refresh
Low refresh IC,full screen with horizontal stripes and ghosting.
Higher grayscale, 16bit or above, high grayscale display can present more vivid and realistic color effects
Grayscale is less than 12 bits, and the color transition of low grayscale display is very abrupt
PCB board
1.6mm PCB board, 33% thicker than other LED modules, not easy to deform, so the screen is more flat.
PCB board
1.2mm PCB board, very poor flatness and unstable quality.
lamp bead
The lamp bead anti-collision capacity is more than 5 kgs,50% higher than others,more solid,more durable.
lamp bead
The lamp beads have an anti-collision capacity of 2-3 kg, and a slight collision will cause the lamp beads to fall off.
